Qingling Isuzu 6x6 Off-Road Foam Fire Truck Released for Global Export
Engineered on the reliable Qingling Isuzu 6x6 chassis, this off-road foam fire truck is specifically built to address rural, forest, and industrial emergency scenarios where standard two-wheel-drive emergency vehicles fail.
Powered by a 3.0L Isuzu diesel engine (105 kW) meeting strict Euro VI / National VI emission standards (GB17691-2018), the vehicle delivers balanced torque and fuel efficiency for off-road operations. With an approach angle of 33° and a departure angle of 39°, the vehicle effortlessly handles steep slopes, unpaved muddy roads, and rugged terrain.
Primary Technical Specifications
Technical Parameter | Specification / Performance Value |
Chassis Model | Qingling Isuzu QL1060CTGR (Double Cab) |
Drive Type | 6×6 All-Wheel Drive |
Engine Displacement / Power | 2,999 cc / 105 kW |
Emission Standard | GB17691-2018 China VI / Euro VI Equivalent |
Overall Dimensions (L×W×H) | 6,900 mm × 1,930 mm × 2,150 mm |
Gross Vehicle Weight (GVW) | 5,900 kg |
Approach / Departure Angle | 33° / 39° |
Minimum Turning Diameter | ≤ 13.5 m |
Maximum Road Speed | 90 km/h |
Seating Capacity | 2 + 3 Personnel |
Firefighting Equipment & Tank Integration
Figure 2: Real-world discharge test of the PS15 roof-mounted fire monitor showing long-range stream reaching elevated industrial structures.
1. Dual-Fluid Storage System (SUS304 Stainless Steel)
The firefighting body features an exterior-mounted tank layout crafted from high-durability 304 stainless steel (Bottom plate: 3mm, Side/Top plates: 2mm). Internal anti-corrosion protection includes epoxy primer and epoxy pitch coatings.
Fire Water Pump: Model XD50/110, delivering a rated flow of 13.6 L/s @ 1.0 MPa (Max rated pump displacement: 50 m³/h).
Fire Monitor: Model PS15 roof-mounted water/foam cannon with a rated flow of 15 L/s @ 1.0 MPa.
Power Take-Off (PTO): Electronically controlled PTO system integrated into the Isuzu manual transmission.
Front Equipment Compartments: Constructed with high-strength steel tubing framing and durable aluminum alloy roller shutter doors. Anti-slip roof walkways and folding side steps facilitate safe crew operation.
Mid-Section Liquid Tank: Engineered with automatic pressure relief, overflow protection, dual side filling ports, and manual drain valves.
Rear Pump Control Room: Weather-sealed with tri-side aluminum roller doors, equipped with real-time digital pressure gauges, electronic switches, and night illumination systems.
Emergency Readiness & Auxiliary Equipment Package
To support modern municipal and industrial safety requirements—including EV fire incidents and hazardous material containment—the Isuzu 6x6 foam fire truck comes equipped with comprehensive auxiliary toolkits:
Drive Hand Configurations: LHD (Left-Hand Drive) and RHD (Right-Hand Drive) options available.
Multilingual Operation Panels: English, Spanish, French, and Arabic control interfaces.
CKD/SKD & Complete Vehicle Export: Professional marine roll-on/roll-off (RoRo) and container shipping solutions.
