Isuzu brand Frozen Sea Food Transportation trucks, specially for the transportation of seafood, particularly fish, often requires specialized refrigerated truck Isuzu to maintain the freshness and quality of the products. These freezer trucks Isuzu, such as refrigerated seafood trucks, fish transport trucks, and refrigerated fish delivery vans, are equipped with high-quality refrigeration systems to ensure that the seafood remains at the appropriate temperatures throughout the transportation process.
| Work capacity: | 18 cbm |
| Engine power: | 120 HP |
| Engine type: | Isuzu 4KH1-TC |
| Axle drive: | 4x2 |
| Gear box: | Isuzu MSB |
| Remarks: | Thermo King RV-380 |
| Product Name 产品名称 | KV100 Refrigerated Truck KV100 冷藏车 | |
| Drive Type 型式 | 4X2 | |
| Wheelbase轴距 | Length (mm)长度 | 3360 |
| Cabin chassis Weights底盘重量 | ||
| GVW (kg)总质量 | 7,300 | |
| Curb Weight (kg)整备质量 | 2,300 | |
| Payload(kg)载重 | 5,000 | |
| Axle payload（kg) 轴荷 | Front Axle 前桥 | 2580 |
| Rear Axle 后桥 | 4720 | |
| Size尺寸 | ||
| cabin chassis truck size 底盘尺寸 | Length*Width*Height (mm) | 5995x2030x2280 |
| Wheel Distance（mm) 轮距 | Front 前轮距 | 1685 |
| Rear 后轮距 | 1525 | |
| Cab驾驶室 | ||
| Double/Single双排/单排 | single单排 | |
| Driver & Passenger乘员 | 3 | |
| Engine 发动机 | ||
| Model型号 | 4KH1CN6LB | |
| Emission Standard排放标准 | can working on Euro3&Euro4 | |
| Displacement (L)排量 | 2.999 | |
| Rated Power (KW)额定功率 | 88kw(120hp) | |
| Max. Torque (N.m)最大扭矩 | 290 | |
| Type类型 | 4 Cylinders in line,high presure, electrical common-rail diesel fuel injection system,water cooling , turbo charging, inter cooling. 直列四缸，高压共轨，电控燃油喷射系统，水冷中控系统，带涡轮增压。 | |
| Gear变速箱 | ||
| Transmission变速箱 | Manual ,MSB,5 forward+1 reverse手动挡 | |
| Brake 制动 | ||
| Brake System制动系统 | Oil brake油制动 | |
| Max. Speed (km/h)最大速度 | 115 | |
| Standard Configurations标准配置 | ||
| Tire 轮胎 | 7.00R16LT 14PR | |
| Power Steering动力转向 | ● | |
| Radio 录音机 | ● | |
| A/C空调 | ● | |
| ABS | ● | |
| Tilted cabin | ● | |
| Electric windows | ● | |
| Central locking | ● | |
| Fuel Tank | 100L | |
| Specifcations of cargo box 货箱参数 | ||
| Material材料 | Fiberglass inside and outside, aluminum patterned floor, overall bent 150mm skirt, two hinges for the rear door, 304 stainless steel hardware, left and right side protection, rear protection, four corner light strips, six riding cards, beam rubber, reflectors, upper assembly, debugging and testing. 内外玻璃钢，铝花纹地板，整体折弯150mm裙边，后门为两个铰链，304不锈钢五金件，左右侧防护，后防护，四角灯带，六个骑马卡，大梁胶皮，反光片，上装组装、调试、检测。 | |
| Specifcations of Refrigerator冷机参数 | ||
| Refrigerator unit 冷机型号 | RV580 | |
| Cooler Brand 冷机品牌 | Thermo KING | |
| Specifcations of Refrigerator货箱参数 | ||
| Door on the Van 货箱门 | 2 doors on the back If need side open door,need custom and inform when enquiry | |
| Van Dimension reference 货箱尺寸 参考 | Length*Width*Height (mm) | 4100x1900x1800mm |
