Light Dumper lsuzu
The Isuzu KV100 dump truck is economical, practical, efficient and reliable, and is suitable for various light transport tasks, such as short-distance urban distribution, urban logistics transportation, etc. The Isuzu KV100 dump truck has a solid structural design, abundant power, stable control, safety and reliability, and is a small commercial vehicle chassis favored by users.
| Work capacity: | 3～6tons |
| Engine power: | 120HP |
| Engine type: | 4HK1CN6LB |
| Axle drive: | 4x2,LHD |
| Gear box: | MSB-5MT |
| Remarks: | Isuzu KV100 3x cabin truck chassis |
KV100 Dump Truck Parameters
| 自卸车：Dump Truck | |
| 产品名称：NKR KV100 Dump Truck | |
| I. General Information | |
| Reference Overall Dimensions(mm): | 5995*2130*2400 |
| Capacity(CBM) / Payload(kg): | 3m³/2500-3000kg |
| GVW(kg): | 7300 |
| II. Chassis | |
| Chassis Model: | ISUZU NKR KV100 |
| Drive Type: | 4x2 |
| Wheelbase(mm): | 3360 |
| Cabin: | Single |
| Seats: | 3 |
| Tire Model: | 7.00R16LT 14PR |
| Standard Configuration: | A/C, ABS, power steering, etc. |
| III. Engine | |
| Model: | 4KH1CN6LB |
| Power (HP/kw): | 120HP/88kw |
| Displacement: | 2.999L |
| Engine Type: | 4-cylinder in-line, turbocharged, etc. |
| Fuel Type: | Diesel |
| Emission Standard: | Euro3/Euro4/Euro5/Euro6 |
| IV. Upper Body Specifications | |
| Size(mm): | 3800X2000X400 |
| Unloading Way: | Domestic Single or Double cylinder abdominal lift |
| Thickness(mm): | Bottom plate 4mm/side plate 3mm |
| V.Optional Configurations | |
| For more optional configurations and requirements, please contact our sales manager directly. | |
